Vertical Wheel Repair Machine AWR904VP


AWR904VP is an upgrade model of 902. The machine adopts a vertical design, cast iron body, six linear guide-rails and a gantry structure, which can ensure that the machine is more stable and the cutting effect is better during repair process. The max. cutting size can reach to 35’’, while wheel’s thickness reach to 450mm. At the same time, it adopts many user-friendly and convenient designs: automatic tool-holder, pneumatic chip removal device, multi-touch screen, customizable logo lights etc., which are easy to operate, save time and labor costs. At the same time, its floor space is only 1.68m2, which is easy to move. AWR904VP is currently the most classic model.

Specifications

Control system: Multi-touch industrial PC system

Optimization software: Crystal CNC-WheelCurve Software V2.0

Max. turning diameter: 814mm

Max. size of alloy wheel: 35”

Max. depth of wheels: 590mm

Chuck type: 13’’ 3 jaw chuck (6 jaw optional)

X/Z axis accuracy: 0.001mm

X/Z axis control mode: Servo control

Range of spindle speed: 50-1500rpm

Tool post: 4 position automatic tool holder

Detection method: Ruby probe (Laser detection optional)

Machine base: Whole cast iron base

Machine motors power: 9.02kw

Voltage: 3phase 380V (Other voltage optional)

Color: Customizable

Machine size: 1650*1020*1960

Net weight: 1350kg
