1. Four-station electric tool holder, one-button switching, fast and convenient.
2. X/Z axis linear guide rail, high processing precision and fast movement speed.
3. 17-inch industrial display screen, touch control, multi-language optional.
4. A clear interface and simplified workflow allow new operators to learn quickly.
5. Self-developed wheel repair software can automatically optimize.
6. The guide rail fully protected to extend the service life.
7. Straighten function optional, which is cost-effective and efficient.
8. The X/Z stroke are increased to meet the cutting needs of different sizes.
Control system & Software: 17" PC & CRYSTAL V3.0
Max. wheel cutting size: 29inch
X/Z axis travel: 400/800mm
No.& type of guide in X/z axis: 2/4 linear guide-rails
Chuck & claw: 13" chuck with 3 extended claw (6 claw available)
Range of spindle speed: 10-1500rpm
Machine motors power: 7.23Kw
Type of tool holder: 4 position electric tool holder
Detection method: Ruby contact probe
Power supply: 3P 380V 50/60Hz
Machine/Packing size (L*W*H): 2130*1200*1935/2250*1300*2250mm
Net/Gross weight: 1320/1220Kg
HS code: 8458110090
1. Wireless key&mouse 1 set
2. Diamond cutter 1 set left
3. Diamond cutter 1 set right
4. Special ordered soft jaws 1 set
5. High precision prob system 1 set
6. 4 station electric tool holder
7. Full cover safety door
8. English version manual instruction and training video
9. Automatic lubrication system, cooling system, lighting system
